The SCP series are a range of extremely powerful compact dual-channel power amplifiers for commercial use. These half 19” devices can be used in stereo low impedance or 70/100V bridge mode. There are 5 different models to serve a wide range of applications with power ratings that vary between 120W up to 1000W in a half 19” rack space housing.
The compact and elegant design of the half 19” rack space enclosure allows for single installation in a 10.5” equipment rack, or side-by-side (two devices) in a 19” equipment rack. Of course, desktop installation or mounting in an equipment rack using the MBS310 series mounting adapters is possible.
Equipped with a standby mode switch, the SCP series will enter an energy-saving standby mode after a period of inactivity making it unique in the market. This feature together with the overall energy efficient design makes the SCP meet the high standards of the Energy star certification.
SYSTEM SPECIFICATIONS
| Continuous power (AES) | @ 4 Ω Stereo | 2 x 240 W | |
| @ 8 Ω Stereo | 2 x 120 W | ||
| @ 70/100 V Bridge | 480 W | ||
| Frequency | Response (± 3 dB) | 20 Hz – 20 kHz | |
| THD+N (@ 1 kHz) | <0.05% | ||
| Signal / Noise | > 95 dB | ||
| Indicators | VU LED bar (front) | ||
| Outputs | Voltage / Impedance | 70-100 V / 4 Ω | |
| Connector | 4-pin Euro Terminal Block (Pitch – 5.08 mm) | ||
| Inputs | Connector | 3-pin Euro Terminal Block (Pitch – 3.81 mm) | |
| IEC C14 Connector | |||
| Other | Connector | RJ45 | |
| Type | 1 x Remote Volume controller | ||
| 1 x Remote Wall Mixer | |||
| Priority mute contact | |||
| Stereo – BTL/HPF mode configuration | |||
| Power | Standby switch | ||
| Supply | 100 ~ 240 V AC / 50 ~ 60 Hz | ||
| Control | Gain control potentiometers (rear) | ||
| Stereo Low Z & Mono High Z switch | |||
| 70/100V switch | |||
| Cooling | Temperature controlled fan | ||
| Technology | Class-D | ||
PRODUCT FEATURE
| Dimensions | 217.5 x 44 x 300 mm (W x H x D) | |
| Weight | 2.75 kg | |
| Construction | Steel | |
| Mounting | 1/2 19” / 1 HE or tabletop | |
| Accessories | Optional | WP2xx Universal wall panel |
| 19” Rackmount adapter | ||
