QSC RMX5050a
Two-Channel Power Amplifier
FEATURES
- Compact size — up to 2500 watts in two rack spaces, or 5000 watts in three rack spaces
- High-current toroidal transformers, for greater 2-ohm power and low noise
- Independent user-defeatable clip limiters reduce distortion
- Selectable low-frequency filters (30 Hz or 50 Hz) protect speakers and increase headroom
- The 4000-watt RMX4050a operates on a standard 15 amp plug (120V)
- Both the RMX4050a and the RMX5050a feature a dual mono, high-current power supply for increased reliability and performance
- The RMX4050a’s particularly exceptional combination of cooling capacity and electrical efficiency provides robust thermal performance suitable for high continuous power in 2-ohm stereo or 4-ohm bridged applications.
- Balanced 1/4-inch (6.3 mm) TRS, XLR, and barrier strip inputs
- Touch-proof binding post and Neutrik Speakon® outputs
- Front mounted gain controls for easy access
- Signal and clip LED indicators for monitoring performance
- Independent DC and thermal overload protection on each channel automatically protects amplifier and speakers
- 3-year warranty plus optional 3-year extended service contract
SPECIFICATIONS
| Specification | RMX 2450a |
|---|---|
| Power per Channel (Stereo) | |
| 8Ω, FTC 20 Hz–20 kHz, 0.1% THD | 450 W |
| 8Ω, EIA 1 kHz, 0.1% THD | 500 W |
| 4Ω, FTC 20 Hz–20 kHz, 0.1% THD | 650 W |
| 4Ω, EIA 1 kHz, 0.1% THD | 800 W |
| 2Ω, EIA 1 kHz, 1% THD | 1200 W |
| Bridge-Mono Mode | |
| 8Ω, FTC 20 Hz–20 kHz, 0.1% THD | 1300 W |
| 8Ω, EIA 1 kHz, 0.1% THD | 1500 W |
| 4Ω, EIA 1 kHz, 1% THD | 2400 W |
| 100V Direct Drive | 2300 W |
| Signal to Noise (20 Hz–20 kHz) | -100 dB |
| Distortion (SMPTE-IM) | < 0.01% |
| Input Sensitivity at 8Ω | 1.42V (+5.3 dBu) |
| Voltage Gain | 50x (34 dB) |
| Output Circuitry | 3-tier Class H |
| Current Draw (120V AC) | Typical: 6.3 A, Severe: 15.6 A |
| AC Plug | NEMA 5-20 (100/120V), CEE7/7 (230V) |
| Distortion (typical) | < 0.02% (4Ω and 8Ω) |
| Frequency Response | 20 Hz–20 kHz: +0/-1 dB |
| Damping Factor (1 kHz) | > 250 at 8Ω |
| Input Impedance | 10 kΩ unbalanced, 20 kΩ balanced |
| Input Stage Clipping | 6.4 V rms (+18 dBu) |
| Cooling | Variable speed fan, back-to-front |
| Connectors | Inputs: XLR, Euroblock; Outputs: Binding posts, Speakon® |
| Controls | Front: AC switch, gain knobs; Rear: DIP switch |
| LED Indicators | Power, Signal, Clip/Protect |
| Amplifier Protection | Full protection |
| Load Protection | Triac crowbar |
| Dimensions (H×W×D) | 89×482×404 mm / 3.5×19×15.9 in (2RU) |
| Carton Dimensions | 610×560×153 mm / 24×22×6 in |
| Net Weight | 20.2 kg / 44.5 lb |
| Shipping Weight | 23 kg / 50.5 lb |
