The ALTI4 is a 2-way pendant loudspeaker featuring a 4” driver combination with a coaxially mounted 1” soft dome tweeter and is fitted with a phase plug for excellent off-axis performance.
SYSTEM SPECIFICATIONS
| Peak power handling | 120 W | |
| Program power handling | 60 W | |
| Continuous power (AES) | 30 W | |
| Speaker type | 2-way coaxial | |
| Drivers | 4” | |
| Impedance | 16 Ω | |
| Line Transformer Tappings | 1 | 208 Ω – 100 V / Not used – 70 V / 24 W |
| 2 | 417 Ω – 100 V / 24 W – 70 V / 12 W | |
| 3 | 833 Ω – 100 V / 12 W – 70 V / 6 W | |
| 4 | 1667 Ω – 100 V / 6 W – 70 V / 3 W | |
| Dispersion | Conical | 165° (average 500 Hz to 5 kHz @ -6 dB) |
| Connectors | 4-pin Euro Terminal Block | |
| Sensitivity (1W/1m) | 80 dB | |
| Sound Pressure (Max. W/1m) | @ 16 Ω | 95.1 dB |
| Frequency | Range (-10 dB) | 65 Hz – 20 kHz |
| Response (± 3 dB) | 85 Hz – 20 kHz | |
PRODUCT FEATURE
| Dimensions | 170 x 223 mm (Ø x H) | |
| Connection cable length | 3.5 m | |
| Construction | Polypropylene | |
| Front finish | Aluminium grill | |
| Mounting & handling | Dual snap hook and dual Gripple™ hanger | |
| Accessories | Included | Connection cable with dual steel core, snap hook & open ends – 3.5 meter |
| 2 Gripple™ hangers | ||
| Weight | 2.23 kg | |
VARIANTS
- ALTI4/B – Black version
- ALTI4/W – White version
